HD dm500hd set top box dm500hd satellite tv receiver dm500hd DVB HD DM500HD DM500HD manufacturer from China Shenzhen KeXun E-digital technology Co.Ltd

HD dm500hd set top box dm500hd satellite tv receiver dm500hd DVB HD DM500HD

Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: DM500HD

Brand Name: dreambox

1.DM500HD
2.HD RECEIVER
3.10/100MBit compatible Ethernet Interface
4.DVB-S2
5.HDMI

Powerful receiver for digital TV and Radio programs.

Main features are a 400 MHz processor, DM 500 HD supports the Linux TV API

Have a look to HighDefinition TV on your DB.

10/100MBit compatible Ethernet Interface

HDMI connector
eSATA

400 MHz MIPS Processor
Linux Operating System
2 LED status
MPEG-2 / H.264 Hardware decoding
Tuner: DVB-S2
1 x Smartcard-Reader (Dreamcrypt CA)
eSATA connector
Mini USB for Service and software update
10/100Mbit Ethernet Interface
1 x Scart (RGB, FBAS, YUV or S-Video)
HDMI
analog modem
S/PDIF Interface for digital bit stream out (AC-3)
64 MByte Flash, 256 MByte RAM

unlimited channel lists for TV/Radio
channel-change time < 1 second
automatic service scan
directly bouquet-lists
EPG (electronic program guide)
multiple LNB-Switching control (supports DiSEqC)
OSD in many languages and skin-support
Videotext Decoder
external 12V power supply

DBS-Tuner, DVB-S2:
Frequency Range950 .... 2150 MHz
Demodulation DVB-S (QPSK); DVB-S2 (8PSK,QPSK)
Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/ MCPC
DVB-S2: 10 ? 31 Mbaud/s (8PSK) , 10 ?30 Mbaud/s (QPSK)

Video decoder:
Video Compression MPEG-2 and MPEG-1 compatible, H.246
Video Formats 4:3 / 16:9
Letterbox for 4:3 TV-Device

Audio decoder:
Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
Audio Mode Dual (main/sub), Stereo
Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz

Output analog:
Output Level L/R 0,5 Vss on 600 Ohm
THD > 60 dB (1 kHz)
Crosstalk < -65 dB

Output digital:
Output Level 0,5 Vss on 75 Ohm
Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
S/PDIF-Output optical, Toslink

Ausgang Video:
Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm

Video parameter:
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm
Teletext filter in conformity with ETS 300 472 Standard

TV-Scart:
Output: FBAS, YUV, RGB, S-Video

MiniUSB service connector
Function: Firmware update

Ethernet:
10/100 MBit compatible interface
Function: Firmware update

Analoge modem:
analoge modem for Internet connection

LNB power and polarisation per tuner:
LNB Current 500mA max.; short-circuit-protected
LNB Voltage vertical < 14V no load, > 11,5V at 400mA
LNB Voltage horizontal < 20V no load, > 17,3V at 400mA

Count of active satellite position:
DiSEqC 1.0/1.1/1.2 and USALS - Rotor Control

Power consumption:
< 12W at 12V in operation
< 1W in standby

External PSU
Input:
110-240V AC / 50-60Hz / 0,6A
Output:
12V = / 3,0A

Physical specification:
Ambient Temperature +15°C...+35°C
Humidity < 80%
Size (W x D x H): 195 mm x 130 mm x 40 mm
Weight: 0,7 kg
